EZ800/EZD Control Commands
MN05013001E130
Boolean sequence function blocks BV01 .. BV32
Telegram structure
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 94
1Command:
Read 92 –
Write B2 –
Response:
Read successful – C2
Write successful – C1
Command
rejected
– C0
2Type 13 13
3 Instance 01 – 20 01 – 20
4 Index J Table 64 J Table 64
5 – 8 Data 1 – 4
Read operation 00 depending on
index,
J Table 65, 66
Write operation
depending on
index,
J Table 65, 66
00
