For more information visit: www.EatonElectrical.com
Appendix
MN05013001E190
PROFIBUS-DP
Device connection SUB-D 9-pole, socket
Electrical isolation Bus to power supply (simple)
Bus and power supply to EZ basic unit (safe isolation)
Function PROFIBUS-DP slave
Interface RS 485
Bus protocol PROFIBUS-DP
Baud rates Automatic search up to 12 MBd
Bus terminating resistors
Connectable via plug
Bus addresses
1 to 126 addressable via EZ basic unit with display or EZSoft
Services
Inputs module All data S1 to S8 (EZ/EZD)
Outputs module All data R1 to R16 (EZ/EZD)
Control commands module Read/Write
Time, day, summer/winter time (DST)
All parameters of the EZ function relays
