Eaton PROFIBUS-DP EZ204-DP User Manual

For more information visit: www.EatonElectrical.com
EZ800/EZD Control Commands
MN05013001E166
Operating hours counters OT01 .. OT04
Telegram structure
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 94 J page 94
1Command:
Read 92 –
Write B2 –
Response:
Read successful – C2
Write successful – C1
Command
rejected
– C0
2Type 1E 1E
3 Instance 01 – 04 01 – 04
4 Index J Table 102 J Table 102
5 – 8 Data 1 – 4
Read operation 00 depending on
index,
J Table 103
Write operation
depending on
index,
J Table 103
00
