EZ800/EZD Control Commands
MN05013001E102
Read inputs of the stations IW1 to IW8
The EZ800 and EZD devices can be remotely expanded very
simply using the EZ-NET. The service offered here makes it
possible to implement read access to the inputs of individual
NET stations.
Telegram structure
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 94
1 Command: Read
91 –
Response:
Read successful – C2
Command
rejected
– C0
2Len
02 02
3Type
01 01
4 Index 01 – 08
1
01 – 08
1
5 Data 1 (Low Byte) 00 J Table 45
on Page 100.
6 Data 2 (High Byte) 00
7 – 8 Data 3 – 4 00 00
1) Corresponds to address of network station
