Eaton PROFIBUS-DP EZ204-DP User Manual

For more information visit: www.EatonElectrical.com
EZ800/EZD Control Commands
MN05013001E162
Master reset function blocks MR01 .. MR32
Telegram structure
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 94
1 Command: Read
92 –
Response:
Read successful – C2
Command
rejected
– C0
2Type
0F 0F
3Instance
01 – 20 01 – 20
4 Index
Bit IO 00 00
Mode 01 01
5 – 8 Data 1 – 4 00 depending on
index,
J Table 97, 98
