Page #72 background image
For more information visit: www.EatonElectrical.com
Control commands for EZ700
MN05013001E68
Timing relays: T1 – T16
The following commands are used to read the logic state of
the individual timers T1 - T16.
Telegram structure
Table 20: Byte 5 to 6: Data 1 to 2
Byte Meaning
Value (hex), sent by
Master Slave
0 Toggle byte J page 44
1 Command: Read
88
Response:
Read successful C2
Command
rejected
C0
1
2Len 01 01
3Type
ED ED
4 Index 00 00
5 Data 1 (Low Byte) 00 J Table 20
6 Data 2 (Low Byte) 00 J Table 20
7 – 8 Data 3 – 4 00 00
1) Possible causes J page 91
Data 1 Bit 7 6 5 4 3 2 1 0
T1 0/1
T2 0/1
... ...
T8 0/1
Data 2 Bit 7 6 5 4 3 2 1 0
T9 0/1
T10
0/1
... ...
T16 0/1
