Control commands for EZ700
MN05013001E70
Master reset: Z1 – Z3
Telegram structure
Table 22: Byte 5: Data 1
Byte Meaning
Value (hex), sent by
Master Slave
0 Toggle byte J page 44
1 Command: Read
88 –
Response:
Read successful – C2
Command
rejected
– C0
1
2 Len 01 01
3Type
93 93
4 Index 00 00
5 Data 1 (Low Byte) 00 J Table 22
6 – 8 Data 2 – 4 00 00
1) Possible causes J page 91
Data 1 Bit 7 6 5 4 3 2 1 0
Z1 for Q outputs 0/1
Z2 for M markers 0/1
Z3 for outputs and
markers
0/1
... 0 0 0 0 0
