EZ800/EZD Control Commands
MN05013001E168
Send network data function blocks PT01 .. PT32
Telegram structure
Table 104: Operand overview
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte J page 94
1 Command: Read
92 –
Response:
Read successful – C2
Command
rejected
– C0
2Type
1F 1F
3Instance
01 – 20 01 – 20
4 Index J Table 104
5 – 8 Data 1 – 4 00 depending on
index,
J Table 105
Index
(hex)
Operand Read Write
00 Bit IO, J Table 105 ×
01 Mode/Parameter – –
02 Input value: Setpoint that
it transmitted to the NET
network
I1 ×
J
The data for index 2 is transferred as a 32-bit value in Intel
format (Data 1 – Low Byte to Data 4 – High Byte).
