Electrical isolation
For more information visit: www.EatonElectrical.comMN05013001E 21
Electrical isolation The following electrical isolation should be provided for the
interfaces of the EZ204-DP:
Figure 6: Potential isolation between the power supply and
outputs
 Safe isolation of EZ-LINK 240 V AC
 Simple isolation of PROFIBUS-DP
 24 V DC supply voltage
M4
EZB4-102-KS1
EZB4-102-KS1
a
c
b
+ –
