Control commands for EZ700
MN05013001E52
Counters: C1 – C16
The following commands are used to read the logic state of
the individual counters C1 – C16.
Telegram structure
Table 11: Byte 5 to 6: Data 1 to 2
Byte Meaning
Value (hex), sent by
Master Slave
0 Toggle byte J page 44
1 Command: Read
88 –
Response:
Read successful – C2
Command
rejected
– C0
1
2Len 01 01
3Type
EE EE
4 Index 00 00
5 Data 1 (Low Byte) 00 J Table 20
6 Data 2 (Low Byte) 00 J Table 20
7 – 8 Data 3 – 4 00 00
1) Possible causes J page 91
Data 1 Bit 7 6 5 4 3 2 1 0
C1 0/1
C2 0/1
... ...
C8 0/1
Data 2 Bit 7 6 5 4 3 2 1 0
C9 0/1
C10
0/1
... ...
C16 0/1
