Device setup
For more information visit: www.EatonElectrical.comMN05013001E 13
Device setup
Figure 2: View of the device
PROFIBUS-DP connection, 9-pole SUB-D socket
24 V DC supply voltage
Device designation plate
BUS communication LED
POW operation LED
EZ-LINK socket
POW
BUS
f
e
a
d
c
b
