Read/write image data
For more information visit: www.EatonElectrical.comMN05013001E 101
Example: Read local inputs IW0
The values Data 1 = C4 and Data 2 = 02 indicate that the
inputs I8, I7, I3 and I10 have been set to 1.
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte 81 80
1 Command: Read
91 –
Response: Read
successful
– C2
2 Len
02 02
3Type
01 01
4 Index
00 00
5Data 1
00 C4
6Data 2 00 02
7Data 3 00 00
8Data 4 00 00
J
All values must be transferred as hexadecimal values.
