EZ800/EZD Control Commands
MN05013001E146
Table 79: Operand overview
Table 80: Index 0 – Bit IO
Index
(hex)
Operand Read Write
00 Bit IO, Table 80 ×
01 Mode/Parameter – –
02 Input value: value that
is transferred to the
QV output when the
FB is triggered.
I1 × c
1
03 Output value QV ×
1) The value can only be written if it is assigned to a constant in
the program.
J
The data for index 2 and 3 is transferred as a 32-bit value in
Intel format (Data 1 – Low Byte to Data 4 – High Byte).
Bit 7 6 5 4 3 2 1 0
FB input Data 1 – – – – – – – T
1
FB output Data 3 – – – – – – – Q1
2
1) Transfer of the value present at I1 on rising edge.
2) Status 1 if the trigger signal is 1.
