Read/write image data
For more information visit: www.EatonElectrical.comMN05013001E 119
Example 2
Write marker word MW32 with 823
823
dec
= 337
hex
J Data 1 = 37
hex
, Data 2 = 03
hex
Byte Meaning Value (hex), sent by
Master Slave
0 Toggle byte 81 80
1 Command: Write
B1
Response:
Write successful
C1
2 Len
02 02
3Type 0D 0D
4 Index 20 20
5Data 1
37 00
6Data 2 03 00
7Data 3 00 00
8Data 4 00 00
