Read/write function block data
For more information visit: www.EatonElectrical.comMN05013001E 143
Table 77: Operand overview
Index
(hex)
Operand Read Write
00 Bit IO, J Table 78 ×
01 Mode/Parameter – –
02 Text line 1, column 1 - 4 ×
03 Text line 1, column 5 - 8 ×
04 Text line 1, column 9 - 12 ×
05 Text line 1, column 13 - 16 ×
06 Text line 2, column 1 - 4 ×
07 Text line 2, column 5 - 8 ×
08 Text line 2, column 9 - 12 ×
09 Text line 2, column 13 - 16 ×
10 Text line 3, column 1 - 4 ×
11 Text line 3, column 5 - 8 ×
12 Text line 3, column 9 - 12 ×
13 Text line 3, column 13 - 16 ×
14 Text line 4, column 1 - 4 ×
15 Text line 4, column 5 - 8 ×
16 Text line 4, column 9 - 12 ×
17 Text line 4, column 13 - 16 ×
18 Variable 1 × c
1
19 Variable 2 × c
1
20 Variable 3 × c
1
21 Variable 4 × c
1
22 Scaling minimum value 1 ×
23 Scaling minimum value 2 ×
24 Scaling minimum value 3 ×
25 Scaling minimum value 4 ×
26 Scaling maximum value 1 ×
