Read/write function block data
For more information visit: www.EatonElectrical.comMN05013001E 149
Table 82: Index 0 – Bit IO
Table 83: Index 1 - Mode
Bit 7 6 5 4 3 2 1 0
FB input Data 1 – – – SE
1
ED
2
EI
3
EP
4
EN
5
FB output Data 3 – – – – – – – LI
6
1) Transfer of manual manipulated variable on status 1
2) Activation of D component on status 1
3) Activation of I component on status 1
4) Activation of P component on status 1
5) Activates the function block on status 1.
6) Status 1 if the value range of the medium-voltage was exceeded
Data 1 Operating mode
UNP
unipolar
The manipulated variable is output as a unipolar 12-bit
value. Corresponding value range for QV 0 to 4095.
BIP
bipolar
The manipulated variable is output as a bipolar 13-bit
value. Corresponding value range for QV –4096 to
4095
