Eaton PROFIBUS-DP EZ204-DP User Manual

Maximum distances/bus cable
For more information visit: www.EatonElectrical.comMN05013001E 23
Distance between stations when using Type A cable to
IEC 61158:
Distance between two stations when using Type B cable to
IEC 61158:
Baud rate
[Kbit/s]
Max. cable length
Type A cable
[m]
9.6 1200
19.2
1200
93.75 1200
187.5 1000
500 400
1500 200
3000 100
6000 100
12000
100
Baud rate
[Kbit/s]
Max. cable length
Type B cable
[m]
9.6 1200
19.2
1200
93.75
1200
187.5 1000
500
400
1500 –
