Eaton PROFIBUS-DP EZ204-DP User Manual

For more information visit: www.EatonElectrical.com
Inputs/Outputs, EZ700/800/EZD Operating Mode
MN05013001E40
Table 4: Byte 1: Write status of R9 to R16
Example:
EZ/EZD
Input
Bit
7 6 5 4 3 2 1 0
R9 0/1
R10 0/1
R11 0/1
R12 0/1
R13 0/1
R14 0/1
R15 0/1
R16 0/1
Value 19
hex
R13, R12 and R9 should be active.
