For more information visit: www.EatonElectrical.com
Control commands for EZ700
MN05013001E74
Table 24: Operand overview
Index
(hex)
Operand Read Write
00 Parameters J Table 25 ×
01 Control byte J Table 26 ×
02 Comparison value 1 I1
2
× c
1
03 Comparison value 2 I2
2
× c
1
04 Gain factor for I1
(I1 = F1 × I1)
F1
2
× c
1
05 Gain factor for I2
(I2 = F2 × I2)
F2
2
× c
1
06 Offset for value I1 (I1 = OS +
actual value at I1)
OS
2
× c
1
07 Switching hysteresis for
value I2
HY
2
× c
1
1) The value can only be written if it is assigned to a constant in the
program.
2) A 16-bit value is transferred in data bytes Data 1 – Data 2. It should be
remembered that the low byte 1 is in Data 1 (Byte 5) and the high byte
2 (byte 8) in Data 2.
Example: 5327
dec
= 14CF
hex
l Data 1 = 0×CF, Data 2 = 0×14
