For more information visit: www.EatonElectrical.com
Control commands for EZ700
MN05013001E80
Table 31: Index 00 – Parameters
Example:
Data 1 (Byte 5) = 0x01
Meaning:
The values appear in the Parameter menu.
Table 32: Index 01 – Control byte
Example:
Index 02/03
Transferred values: Data 1 0x21
Data 2 0x23
Data 3 0x40
Data 4 0x00
Resulting value: 00402321
hex
= 4203297
dec
Meaning Bit 7 6 5 4 3 2 1 0
Appears in the parameter menu
Yes/no 0/1
Use in the program
Setpoint S1 0/1
Unused bits – – – – – –
Data 1 Bit 7 6 5 4 3 2 1 0
FB output – – – – – RE
3
EN
2
Q1
1
1) Switch contact
2) Enable, the timing relay is started (trigger coil)
3) Reset, the timing relay is reset (reset coil)
