Read/write function block data
For more information visit: www.EatonElectrical.comMN05013001E 89
Table 39: Operand overview
Index
(hex)
Operand Read Write
00 ParametersJ Table 40 ×
01 Control byteJ Table 41 ×
11 Channel A Day on/off × c
1
12 On time × c
1
13 Off time × c
1
21 Channel B Day on/off × c
1
22 On time × c
1
23 Off time × c
1
31 Channel C Day on/off × c
1
32 On time × c
1
33 Off time × c
1
41 Channel D Day on/off × c
1
42 On time × c
1
43 Off time × c
1
1) The value can only be written if it is assigned to a constant in
the program.
2) A 16-bit value is transferred in data bytes Data 1 – Data 4. It
should be remembered that Data 1 is the low byte and Data 2
the high byte.
