Chapter 5 Preparations before Operation
WARNING
The performance and electric shock protection can be guaranteed only if original EDAN
patient cable and electrodes are used.
5.1 Connecting the Patient Cable to Electrodes
Electrode includes one chest lead wire and four limb wires connected to electrodes according to
the colors and identifiers.
1. Connect the patient cable to the ECG sampling box. For details, see Chapter 3, “Assembling
VE-1010 VET PC ECG System”.
2. Align all lead wires of the patient cable to avoid twisting, and connect the lead wires to the
corresponding electrodes according to the colors and identifiers. Firmly attach them.
5.2 Attaching Electrodes
Main Cable
Lead Wires
Connecting to the
ECG Sampling Box
Electrodes
Electrode Connectors
Clamp
Screw
