VE-1010 Veterinary PC ECG User Manual Introduction

- 7 -

WARNING

The system should be installed by a qualified service engineer. Do not power on the

system until all cables are properly connected and verified.

2.1 ECG Sampling Box Appearance

ECG Sampling Box Appearance

Front Panel

Name Explanation

Lamp

When the ECG sampling box is powered by the PC, the lamp

will be lit.

USB Socket

Connecting to the USB socket of the PC with a USB cable

Lamp USB Socket
