VE-1010 Veterinary PC ECG User Manual Introduction
- 8 -
WARNING
1. When the computer connected to the USB cable is powered on, do not connect or
disconnect the USB cable to the ECG sampling box.
2. It is not necessary or recommended to regularly disconnect the USB cable from the
ECG sampling box. Disconnect the USB cable from the PC if necessary.
USB Socket
Definitions of corresponding pins:
Pin Signal Pin Signal
1
GND
6
GND
2
VCC
7
GND
3
QRS
8
GND
4
GND
9
D-
5
GND
10
D+
Back Panel
Patient Cable Socket
