VE-1010 Veterinary PC ECG User Manual Configuring the System
- 52 -
8.2.3 Setting Sampling Time
You can enter the normal ECG sampling time manually. The range is 10~600s.
You can enter the HRV sampling time manually. The range is 1~15min.
You can set the HRV analysis lead to one of the 6 leads (І, П, Ш, aVR, aVL, aVF) or 7 leads (І, П,
Ш, aVR, aVL, aVF, V).
8.2.4 Setting Lead Sequence
You can set Lead Sequence to Standard or Cabrera, and the lead groups are displayed or
printed in the corresponding sequence listed in the following table.
Lead Sequence Lead group 1 Lead group 2 Lead group 3
Standard
І, II, Ш aVR, aVL, aVF V
Cabrera
aVL, І, -aVR II, aVF, Ш V
If the Lead Sequence is changed, click on OK button to save the change, and enter the System
Setting interface again, the rhythm lead sequence of print format on the Printer Setting interface
will change correspondingly.
You can set Lead Mode to 6 Leads or 7 Leads.
You can set the HR calculation to one of the 6 standard leads: І, П, Ш, aVR, aVL, aVF or one of
the 7 standard leads: І, П, Ш, aVR, aVL, aVF, V.
8.2.5 Setting Background Grid
Select Background Grid, the grid on the background of the ECG sampling interface and Normal
Analysis interface will be displayed.
Deselect Background Grid, the grid on the background of the ECG sampling interface will not
be displayed.
8.2.6 Setting Anti-aliasing
Select Anti-aliasing, the system will automatically make the waveform smooth.
Deselect Anti-aliasing, the system will not make the waveform smooth.
8.2.7 Selecting QRS Voice
If you select QRS Voice, there will be a beep when an R wave is detected in succession.
