VE-1010 Veterinary PC ECG User Manual Technical Specifications
- 66 -
Accuracy: ±1 BPM
Memory
Memory: Storage amount depends on PC machine
ECG Sampling Box Performance
Leads Mode: 6/7 leads
Acquisition Mode: simultaneously 6/7 leads
Sample Frequency: DP12 ECG sampling box: 1,000 /sec/channel
A/D Resolution: DP12 ECG sampling box: 24 bits
Time Constant: ≥3.2 s(0, +20%)
Frequency Response: 0.05 Hz ~ 150 Hz (-3 dB)
Gain: 0.625, 1.25, 2.5, 5, 10，20, 40(mm/mV)
Input Impedance: DP12 ECG sampling box≥50 MΩ (10Hz)
Input Circuit Current: ≤0.05 μA
Input Voltage Range <±5 mVpp
Calibration Voltage: 1 mV± 2%
DC Offset Voltage DP12 ECG sampling box: ±600mV
Noise: DP12 ECG sampling box≤12.5μVp-p
Work Frequency
DFT Filter: weak/strong
Filter
LOWPASS Filter: 25 / 35 / 45 / 75 / 100 / 150 (Hz)
CMRR
DP12 ECG sampling box≥110 dB
Note: Test the accuracy of input signal reproduction according to the methods described
in clause 4.2.7.2 in ANSI/AAMI EC11:1991/(R) 2001, and the result complies with
clause 3.2.7.2 in ANSI/AAMI EC11:1991/(R) 2001.
