Specications
General
Table 7–1 General specications
Specification Value
Dimensions (W×H×D) 355×288×127 mm (14.0×11.3×5.0 in)
Weight With batteries
Without batteries
6.6 kg (14.5 lb)
5.7 kg (12.5 lb)
Volume 13 L (791 in
3
)
Power requirements 100–240 VAC ±10 %
50–60 Hz
Power supply Direct VAC (100 W) or onboard batteries
Maximum input frequency 1.5 A
Batteries Type
Typical life
Li204SX-7800 rechargeable lithium-ion, DOT compliant
6–8 hours (with both batteries in instrument)
System warm-up time 15 minutes
This is the time necessary for Reddy
®
to reach its optimal accuracy after being turned on. We recommend
that you wait 15 minutes before balancing probes or performing acquisitions.
Display 26.4 cm (10.4 in)
Non-reective (AR coating)
Anti-ngerprint (oleophobic coating)
3 mm (1/8 in), chemically strengthened glass cover
Optically bonded LCD and touchscreen
Passive backlight enhancement
Video output HDMI
Storage SSD, 100 GB
Cooling Sealed and fanless
Encoders 2 axes, quadrature
Connectivity Gigabit Ethernet, Wi-Fi, Bluetooth, USB 2.0 (×3)
Probe recognition and setup Automatic
Reddy uses an ID device in Eddy probes that contains information to set up acquisitions and conrm
compatibility between the setup and the probe.
Environmental
Table 7–2 Environmental specications
Specification Value
IP rating Designed for IP65
Operating temperature 0–40 °C (32–104 °F)
Operating humidity 95 %, non-condensing
Storage temperature –20–60 °C (–4–140 °F)
Storage humidity 95 %, non-condensing
Pollution degree rating 2
Compliance ASME, EN 61010-1, CE, WEEE, FCC Part 15B, ICES-003, AS/NZS CISPR 22, RoHS
ECA
Table 7–3 Eddy current array specications
Specification Value
Channels Reddy 32
Reddy 64
Reddy 128
32
64
128
Frequency range 5 Hz–10 MHz
Frequencies 2 simultaneous
ECA connector 160-pin array
Multiplexer SmartMUX
™
: integrated, universal, and programmable
