6-1
For more detailed information on the LCD and Select button see Chapter 7: “LCD
Display”.
Reconnect/Boost/Billing Reset Button
The Reconnect button is the top of the two push buttons beside the display. The push
button has a 2.5mm diameter hole through it, allowing it to be sealed using standard
sealing wire. This button may be used to trigger connection of an external contactor.
Holding the button down for at least half a second will connect the customers supply, if
it is enabled for connection. The display will show “Connect”. If it is not enabled, the
display will show “not enabled” and the contactor state will not change.
Pushing both the Select button and the Reconnect button at the same time will cause the
contactor to be disconnected. The message “Disconnect” will be displayed on the LCD.
The Reconnect button can also cause a boost operation for load control outputs,
depending on configuration.
Note that the relay may not change state immediately. If another operation has just been
performed, it may take 60 seconds to perform the requested operation.
EziView can configure what operations are permitted using the button. EziView can
also be used to configure the button as a billing reset button - go to Security Setup and
un-check the Billing Reset Button Disabled checkbox.
Servicing
The meter is not designed for field servicing and has no user serviceable parts. The
meter has no internal fuses. In the event of failure of the meter, contact EDMI or your
local agent for servicing.
6-16 EDMI Atlas Hardware Reference Manual
