EDMI Atlas Mk10 User Manual

3-
4
The sealable screws have 2.15mm diameter holes to accommodate standard sealing
wire.
Under the Terminal Cover
Most of the connections to the meter occur under the terminal cover. Figure 3-4 shows
the terminals available on a 4 I/O / RS-232 meter.
• Figure 3-4 Under the terminal cover of the meter
Diagrammatically, this is shown in Figure 3-5 with the terminal block numbering.
3-4 EDMI Atlas Hardware Reference Manual
