The Mk10 Meter 2-
C h a p t e r
2
Chapter 2 The Mk10 Meter
This chapter covers the basic installation and physical features of the Mk10 meter,
including the UPS (Uninterruptable Power Supply), Special I/O and MK10A variants.
Dimensions and Mounting
Figure 2-1 shows the overall dimensions of the meter with a standard terminal cover.
The height excludes the buttons and the ANSI fitting if present.
Height
Width
Depth
• Figure 2-1 Overall dimensions of the meter
Height = 210 mm, Depth = 74 mm, Width = 166 mm
Height is 240 mm with an extended terminal cover, such as used to house a modem.
