Hanging Extension
The top mounting hole can be extended using a clip in extension, as shown in Figure 5-5
and Figure 5-6. This allows a screw to be inserted after the meter is placed on the wall.
This does however make the meter slightly taller (11.5 mm), and allows the screw to be
removed without removing the terminal cover and removing the other two screws first.
The clip can be easily removed with access to the back of the meter by pushing the
centre part in and sliding the clip out.
• Figure 5-5 The hanger extension clip
• Figure 5-6 Hanging keyhole with the clip fitted
5-4 EDMI Atlas Hardware Reference Manual
