EDMI Atlas Mk10 User Manual

The Mk10E Meter 6-1
C h a p t e r
6
Chapter 6 The Mk10E Meter
This chapter covers the basic installation and physical features of the Mk10E meter.
Dimensions and Mounting
Figure 6-1 shows the overall dimensions of the meter with a standard terminal cover.
The height excludes the buttons and the ANSI fitting if present.
Width
Depth
Height
• Figure 6-1 Overall dimensions of the meter
Height = 262 mm, Depth = 95 mm, Width = 175 mm
