4-1
indicator, connection type indicator for connection through local or remote port and
units and multipliers. The LCD does not have a backlight
• Figure 4-13 LCD with all segments turned on
To progress to the next page, press the Select button. Each time the button is pressed the
display moves to the next page. The display may also be setup to automatically cycle
the display through the pages, pausing if the Select button is pressed.
For more detailed information on the LCD and Select button see Chapter 7: “LCD
Display”.
Reconnect/Boost or Billing Reset Button
An optional Reconnect, Boost, or Billing Reset button may be fitted above the select
button (See Figure 4-14). The push button has a 2.5mm diameter hole through it,
allowing it to be sealed using standard sealing wire.
• Figure 4-14 Location of the Billing Reset / Boost button
When used as a Reconnect button, holding the button down for at least half a second
will connect the customers supply, if it is enabled for connection. The display will show
“Connect”. If it is not enabled, the display will show “not enabled” and the contactor
state will not change.
Pushing both the Select button and the Reconnect button at the same time will cause the
contactor to be disconnected. The message “Disconnect” will be displayed on the LCD.
The Reconnect button can also cause a boost operation for load control outputs,
depending on configuration.
4-14 EDMI Atlas Hardware Reference Manual
