Figure 6-6 gives the terminal spacing of TB1.
• Figure 6-6 TB1 terminal spacing
Terminal Block Variations
There are two variations of the terminal block – one with internal VT to CT links, and
one with external VT to CT links. The external model includes numbering on all
terminals and an optional sealable finger guard. The terminal spacing and locations are
unchanged.
Terminal Cover Tamper Detect
The meter has an optional switch that can detect the opening of the terminal cover. It is
located above and to the left of the terminals (See Figure 6-7). The meter can generate
an EFA alarm and an event in the log when the switch is released by someone opening
the terminal cover.
• Figure 6-7 The terminal cover tamper detect button
Meter Lid Tamper Detect
The meter has an optional switch that can detect the opening of the meter lid. The meter
can generate an EFA alarm and an event in the log when the switch is released by
someone opening the meter lid.
6-6 EDMI Atlas Hardware Reference Manual
