ACX air-cooler
B580-65-880 Issue G
3ACX air-cooler
3.1 Description
An ACX air-cooler is used when a suitable cooling-water supply is not available for the pump or for a mobile pumping
system. The ACX air-cooler is an enclosed electric fan and fixing bracket assembly which is easily fitted to bolt holes
in the base of the pump. The ACX air-cooler has a 24 V d.c. motor which can be powered from a rear panel socket
on the EXC Controller, an EXT DX podule, a TIC, or any suitable electrical supply.
All air-coolers are supplied with side-mounting brackets. The ACX250 is also supplied with an axial-mounting bracket
for optional use with EXT250M pumps only.
The ACX400 air-coolers are available for both axial and radial mounting. It is possible to use both variants
simultaneously if so desired and space allows. TICs can provide power for one fan only.
Refer to the EXT pump instruction manual to check the suitability of air cooling in your particular application.
3.2 Technical data
Table 2 - ACX air-cooler technical data
Electrical supply 20 to 28 V d.c.
Cable type and length 2-core with screen, 3 m long
Cable cores Red (positive), black (negative): unterminated, screen terminated with ring terminal
Pollution degree EN61010 Part 1 Category 2
Equipment type Fixed equipment for indoor use only
ACX75 ACX250 ACX250H
ACX400
Radial
ACX400
AXIAL
ACX500 ACX555
Dimensions: see Figure 5 7 10 12 14 17 19
Approximate mass (kg) 0.38 0.85 0.50 0.70 0.45 0.64 1.28
Rated current (mA) 120 120 100 110 110 100 250
Noise level at 1 m (dBA) < 45 < 45 < 45 < 45 < 45 < 45 < 45
Item Numbers
Model To fit pump Item
Number
ACX75 EXT70/70H/70Hi/75DX/75iDX B580-53-075
ACX250 EXT250M B580-53-150
ACX250H EXT250/250H/250Hi, EXT255H/255Hi/255DX/255iDX B580-53-160
ACX400 radial EXT406PX/EXT400/200/(30i)PX B580-53-455
ACX400 axial EXT406PX/EXT400/200/(30i)PX B580-53-405
ACX500 EXT351/501 B580-53-200
ACX555 EXT555H/555HF/555Hi B580-53-561
