Pump-to-controller cable
B580-65-880 Issue G
8 Pump-to-controller cable
Note: Pump-to-controller cables are not applicable to EXT DX pumps. If you need extension cables for EXT DX
pumps, refer to the Edwards catalogue, or contact your supplier or Edwards.
8.1 Description
Complete cables are available for 80 V pumps in 1, 3 and 5 metre lengths to suit your application.
The EXT250M pump is supplied with an EXC300M Controller and a 1, 3 or 5 metre cable.
8.2 Technical data
8.3 Installation
8.3.1 Unpack and inspect
Remove all packing materials and protective covers and check the cable.
If the cable is damaged, notify your supplier and the carrier in writing within three days; state the Item Number of
the cable together with your order number and your supplier's invoice number. Retain all packing materials for
inspection. Do not use the cable if it is damaged.
8.3.2 Connect the pump-to-controller cable
1. If the pump is operating: switch off the pump, isolate the pump controller from the electrical supply, and wait
until the pump has stopped rotating.
2. If fitted, remove the existing pump-to-controller cable.
3. Fit the new pump-to-controller cable: refer to the controller instruction manual.
Table 8 - Pump-to-controller cables technical data
Pump end connector type MIL-C-26482 (US) 14-19P
Controller end connector
type
QM multipole, 19 pins
Cable Screened, multiway
Item Numbers
Length Pump models Item Number
1 m All EXT pumps except EXT250M D396-18-010
3 m All EXT pumps except EXT250M D396-18-030
5 m All EXT pumps except EXT250M D396-18-050
1 m EXT250M D396-19-010
3 m EXT250M D396-19-030
5 m EXT250M D396-19-050
