EG4 6000XP User Manual

52
17
Battery Wakeup
This setting allows the user to enable or
disable the battery wakeup feature. It is
not applicable if no battery type is
defined.
Range: Enable/Disable
18
Max Generator
Input Power
This setting allows the user to
set the maximum generator
input power.
Range: 0-7369W
Default: 7369
19
PV O-Grid
Enable/Disable
This setting allows the user to
configure the system to only
use PV for loads. Due to
voltage fluctuation, power
output may be inconsistent.
Range: Enable/Disable
Default: Disable
20
Power Save
Function
This setting allows the user to
enable or disable the Power
Save Functions, ‘Green
Function’ and ‘ECO Mode’.
Range: Enable/Disable
The default settings for both
functions are set to disabled.

EG4 6000XP Specifications

General

Nominal DC Voltage	48V
Maximum DC Voltage	500V
Maximum Continuous Output Power	6000W
Frequency	60Hz
Model	EG4-6000XP
Peak Power	12000W
Protection Features	Over Voltage, Over Load, Over Temperature, Short Circuit
Cooling	Fan
