EG4 6000XP User Manual

51
14
AC Charge Setting
To configure AC charging, the user must first enable AC Charging, confirm the full
battery SOC value, and set the confirmation time periods 1, 2, and 3.
AC Charge Control Settings for Voltage and SOC:
Voltage:
Start Voltage: 35.4 – 52V
End Voltage: 48 - 59V
SOC:
Start SOC: 1 – 90%
End SOC: 20 – 100%
AC Charge Control Settings for Start/End Times:
Start Time1-3:
Range: 00:00 – 23:59
Default: 00:00 – 00:00
End Time1-3:
Range: 00:00 – 23:59
Default: 00:00 – 00:00
15
AC Input Load
Timer Settings
This setting allows the user to
set the Start/End times for the
Grid/Utility to supply power to
the load.
Start Time1-3: 00:00 – 23:59
Default: 00:00 – 00:00
End Time1-3: 00:00 – 23:59
Default: 00:00 – 00:00

EG4 6000XP Specifications

General

Nominal DC Voltage	48V
Maximum DC Voltage	500V
Maximum Continuous Output Power	6000W
Frequency	60Hz
Model	EG4-6000XP
Peak Power	12000W
Protection Features	Over Voltage, Over Load, Over Temperature, Short Circuit
Cooling	Fan
