ELNA XPRESSIVE 2 - Showing and Hiding Machine Commands; Showing and Hiding the Stitch Placements in Designs

ELNA XPRESSIVE II 51
User’s Guide
Showing and hiding segments
and segment outlines using
various ribbon tools
You can use ribbon tools to hide selected
segments, hide unselected segments and
show all hidden segments. The Show outlines
tool also allows you to show and hide
segment outlines in any embroidery design.
To show segment outlines:
• Click the Show outlines tool, if not
already selected.
You will see the segment outlines in your
design.
To hide segment outlines:
• Click the Show outlines tool again.
Showing and hiding
machine commands
Use Show Commands to view the locations
on the design where the embroidery machine
performs commands. These locations are
marked with different symbols to display the
command type.
This table shows you the symbol for each
command.
To show commands:
• Click the Show Commands tool in the
window.
To hide commands:
• Click the Show Commands tool
again.
Showing and hiding the
stitch placements in
designs
Use the Show Dots tool to see the anchor
points and stitch penetration points in the
design window. The blue squares in your
design represent the anchor points that
control the shape of the design. The black
dots in your design represent the point where
the embroidery machine needle will penetrate
the fabric.
Command Symbol
Trim
Stop
End
Start
Jump
Blank No symbol
No Command No symbol
Color Change
Changeover
Command Symbol
