EMC Data Domain DS60 User Manual

Figure 90 Adjusting the lift arm bar to just under 17 inches
1
2
<17”
CL4900
Installing the shelf onto the rails
Before you begin
If a shelf with all of the FRUs removed is being installed, the chassis can be installed
without using the lift. If the shelf is populated with FRUs prior to installing, then this
task requires the use of a portable lift.
DANGER
DO NOT ATTEMPT to install a populated shelf without a mechanical lift.
Attempting to install a populated shelf without a lift could damage the equipment
and cause injury to personnel
CAUTION
You should only install a shelf into a cabinet if the cabinet is equipped with anti-
tip features.
Removing and Replacing FRUs
116 EMC Data Domain DS60 Expansion Shelf Installation and FRU Replacement Hardware Guide
