Figure 108 Unclip the cable chains from the tray

CL5500

6. Press the tabs and unclip the cable chains from the tray.

7. Unclip the cable chain baskets and remove the cables from the cable chains.

Remove the cable chains.

8. Re-insert the shelf into the rack.

Figure 109

Push spring clips up to release the tray

CL5523

Removing and Replacing FRUs

132 EMC Data Domain DS60 Expansion Shelf Installation and FRU Replacement Hardware Guide
