Figure 6 Sliding the shelf chassis into the rails
You may need to release sagging tension on the shelf by pulling the lift arms and
tray up slightly.
4. Unlock the casters by lifting up on the locking tabs and carefully slide the shelf
into the cabinet as far as the lift will allow.
Figure 7
Unlocking the casters
Shelf Installation and Removal
Installing the shelf onto the rails 29
