166 Affinity User Guide
www.controltechniques.com Issue Number: 5
Parameter
Range(
Ú) Default(Ö)
Type
OL RFC OL RFC
7.01 T5/6 analog input 1 level ±100.00 %
RO Bi NC PT
7.02 T7 analog input 2 level
±100.0 %
RO Bi NC PT
7.03 T8 analog input 3 level
RO Bi NC PT
7.04 Power circuit temperature 1
-128 to 127
°C
RO Bi NC PT
7.05 Power circuit temperature 2
RO Bi NC PT
7.06 Control board temperature
RO Bi NC PT
7.07 T5/6 analog input 1 offset trim ±10.000 % 0.000 RW Bi US
7.08 T5/6 analog input 1 scaling 0 to 4.000 1.000 RW Uni US
7.09 T5/6 analog input 1 invert OFF (0) or On (1) OFF (0) RW Bit US
7.10 T5/6 analog input 1 destination Pr 0.00 to Pr 50.99 Pr 1.36 RW Uni DE PT US
7.11 T7 analog input 2 mode {0.19}
0-20 (0), 20-0 (1), 4-20.tr (2), 20-4.tr (3),
4-20 (4), 20-4 (5), VOLt (6)
4-20 (4) RW Txt US
7.12 T7 analog input 2 scaling 0 to 4.000 1.000 RW Uni US
7.13 T7 analog input 2 invert OFF (0) or On (1) OFF (0) RW Bit US
7.14 T7 analog input 2 destination {0.20}Pr 0.00 to Pr 50.99 Pr 1.37 RW Uni DE PT US
7.15 T8 analog input 3 mode {0.21}
0-20 (0), 20-0 (1), 4-20.tr (2), 20-4.tr (3),
4-20 (4), 20-4 (5), VOLt (6), th.SC (7),
th (8), th.diSP (9)
VOLt (6) RW Txt US
7.16 T8 analog input 3 scaling 0 to 4.000 1.000 RW Uni US
7.17 T8 analog input 3 invert OFF (0) or On (1) OFF (0) RW Bit US
7.18 T8 analog input 3 destination
Pr 0.00 to Pr 50.99
Pr 0.00 RW Uni DE PT US
7.19 T9 analog output 1 source Pr 5.01 Pr 3.02 RW Uni PT US
7.20 T9 analog output 1 scaling 0.000 to 4.000 1.000 RW Uni US
7.21 T9 analog output 1 mode VOLt (0), 0-20 (1), 4-20 (2), H.SPd (3) VOLt (0) RW Txt US
7.22 T10 analog output 2 source Pr 0.00 to Pr 50.99 Pr 4.02 RW Uni PT US
7.23 T10 analog output 2 scaling 0.000 to 4.000 1.000 RW Uni US
7.24 T10 analog output 2 mode VOLt (0), 0-20 (1), 4-20 (2), H.SPd (3) VOLt (0) RW Txt US
7.25 Calibrate T5/6 analog input 1 full scale OFF (0) or On (1) OFF (0) RW Bit NC
7.26 T5/6 analog input 1 sample time 0 to 8.0 ms 4.0 RW Uni US
7.28 T7 analog input 2 current loop loss
OFF (0) or On (1)
RO Bit NC PT
7.29 T8 analog input 3 current loop loss
RO Bit NC PT
7.30 T5/6 analog input 1 offset ±100.00 % 0.00 RW Bi US
7.31 T7 analog input 2 offset
±100.0 % 0.0
RW Bi US
7.32 T8 analog input 3 offset RW Bi US
7.33 T9 analog output 1 control Fr (0), Ld (1), AdV (2) AdV (2) RW Txt US
7.34 IGBT junction temperature
±200
°C
RO Bi NC PT
7.35 Drive thermal protection accumulator 0 to 100.0 %
RO Uni NC PT
7.36 Power circuit temperature 3
-128 to 127
°C
RO Bi NC PT
7.41 Analog input 2 minimum
±100%
-100% RW
7.44 Analog input 2 maximum 100% RW
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
