174 Affinity User Guide
www.controltechniques.com Issue Number: 5
Parameter
Range(
Ú) Default(Ö)
Type
OL RFC OL RFC
9.01 Logic function 1 output
OFF (0) or On (1)
RO Bit NC PT
9.02 Logic function 2 output
RO Bit NC PT
9.03 Motorized pot output ±100.00 %
RO Bi NC PT PS
9.04 Logic function 1 source 1 Pr 0.00 to Pr 50.99 Pr 0.00 RW Uni PT US
9.05 Logic function 1 source 1 invert OFF (0) or On (1) OFF (0) RW Bit US
9.06 Logic function 1 source 2 Pr 0.00 to Pr 50.99 Pr 0.00 RW Uni PT US
9.07 Logic function 1 source 2 invert
OFF (0) or On (1) OFF (0)
RW Bit US
9.08 Logic function 1 output invert RW Bit US
9.09 Logic function 1 delay ±25.0 s 0.0 RW Bi US
9.10 Logic function 1 destination
Pr 0.00 to Pr 50.99 Pr 0.00
RW Uni DE PT US
9.14 Logic function 2 source 1 RW Uni PT US
9.15 Logic function 2 source 1 invert OFF (0) or On (1) OFF (0) RW Bit US
9.16 Logic function 2 source 2 Pr 0.00 to Pr 50.99 Pr 0.00 RW Uni PT US
9.17 Logic function 2 source 2 invert
OFF (0) or On (1) OFF (0)
RW Bit US
9.18 Logic function 2 output invert RW Bit US
9.19 Logic function 2 delay ±25.0 s 0.0 RW Bi US
9.20 Logic function 2 destination Pr 0.00 to Pr 50.99 Pr 0.00 RW Uni DE PT US
9.21 Motorized pot mode 0 to 3 2 RW Uni US
9.22 Motorized pot bipolar select OFF (0) or On (1) OFF (0) RW Bit US
9.23 Motorized pot rate 0 to 250 s 20 RW Uni US
9.24 Motorized pot scale factor 0.000 to 4.000 1.000 RW Uni US
9.25 Motorized pot destination Pr 0.00 to Pr 50.99 Pr 0.00 RW Uni DE PT US
9.26 Motorized pot up
OFF (0) or On (1) OFF (0)
RW Bit NC
9.27 Motorized pot down RW Bit NC
9.28 Motorized pot reset RW Bit NC
9.29 Binary sum ones input RW Bit NC
9.30 Binary sum twos input RW Bit NC
9.31
Binary sum fours input RW Bit NC
9.32 Binary sum output 0 to 255
RO Uni NC PT
9.33 Binary sum destination Pr 0.00 to Pr 50.99 Pr 0.00 RW Uni DE PT US
9.34 Binary sum offset 0 to 248 0 RW Uni US
9.35 Timer 1 start date {0.52} 0 to 311299 0 RW Uni PT US
9.36 Timer 1 start time {0.53} 0.00 to 23.59 0.00 RW Uni PT US
9.37 Timer 1 stop date {0.54} 0 to 311299 0 RW Uni PT US
9.38 Timer 1 stop time {0.55} 0.00 to 23.59 0.00 RW Uni PT US
9.39 Timer 1 repeat function {0.56} 0 to 6 0 RW Uni PT US
9.40 Timer 1 enable {0.57}
OFF (0) or On (1)
OFF (0)
RW Bit US
9.41 Timer 1 invert RW Bit US
9.42 Timer 1 output
RO Bit PT
9.43 Timer 1 destination {0.58}Pr 0.00 to Pr 50.99 Pr 0.00 RW Uni PT US
9.45 Timer 2 start date 0 to 311299 0 RW Uni PT US
9.46 Timer 2 start time 0.00 to 23.59 0.00 RW Uni PT US
9.47 Timer 2 stop date 0 to 311299 0 RW Uni PT US
9.48 Timer 2 stop time 0.00 to 23.59 0.00 RW Uni PT US
9.49 Timer 2 repeat function 0 to 6 0 RW Uni PT US
9.50 Timer 2 enable
OFF (0) or On (1)
OFF (0)
RW Bit US
9.51 Timer 2 invert RW Bit US
9.52 Timer 2 output
RO Bit PT
9.53 Timer 2 destination Pr 0.00 to Pr 50.99 Pr 0.00 RW Uni PT US
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
