230 Affinity User Guide
www.controltechniques.com Issue Number: 5
Table 12-3 Maximum permissible continuous output current @ 40°C (104°F) ambient for size 1 and 2 standard drives with IP54 insert and
standard fan installed
For the definition of ambient temperature, see section 3.7 Enclosure design and drive ambient temperature on page 49.
Model
Maximum permissible continuous output current (A) for the following switching frequencies
3kHz 4kHz 6kHz 8kHz 12kHz 16kHz
BA1201 5.2
BA1202 6.8
BA1203 9.6 9.3 8.2 7.3
BA1204 11.0 10.6 9.7 9.0 7.7 6.6
BA2201 15.5
BA2202 22.0 20.7 18.0 15.7
BA2203 24.5 23.7 22.0 20.5 17.9 15.6
BA1401 2.8
BA1402 3.8 2.9
BA1403 5.0 3.9 2.9
BA1404 6.9 6.5 5.4 3.9 2.9
BA1405 8.3 7.3 5.8 4.7 3.2 2.3
BA1406 8.3 7.3 5.8 4.7 3.2 2.3
BA2401 15.3 13.3 10.1 7.9
BA2402 20.1 18.4 15.6 13.4 10.1 7.9
BA2403 21.7 19.7 16.4 13.9 10.2 7.7
NOTE
