Figure 3-38 Size 5 E12/E54 drive surface mounting
416mm (16.38in)
1211.4mm
(14.69in)
347.2mm (13.67in)
253.6mm (9.98in)
883.9mm
(34.8in)
∅ 8.5mm
(0.34in)
