14.13 Time Period Signal (TPS) output problems
TPS output problems and recommended actionsTable 14-9:
Problem Possible causes Recommended actions
No TPS output The TPS output is not supported on this
device
TPS wiring is connected to the wrong ter-
minals
Output not powered
External short or low input impedance
Verify that the output loop is powered ex-
ternally.
Check the power supply and power supply
wiring. See Section 14.2.
Verify the output wiring.
Contact Micro Motion.
Loop test failed Power supply problem
Wiring problem
Circuit failure
Verify that the output loop is powered ex-
ternally.
Check the power supply and power supply
wiring. See Section 14.2.
Verify the output wiring.
Contact Micro Motion.
14.14 Using sensor simulation for troubleshooting
When sensor simulation is enabled, the transmitter reports user-specified values for basic
process variables. This allows you to reproduce various process conditions or to test the
system.
You can use sensor simulation to help distinguish between legitimate process noise and
externally caused variation. For example, consider a receiving device that reports an
unexpectedly erratic specific gravity value. If sensor simulation is enabled and the
observed density value does not match the simulated value, the source of the problem is
probably somewhere between the transmitter and the receiving device.
Important
When sensor simulation is active, the simulated value is used in all transmitter outputs and
calculations. Disable all automatic functions related to the transmitter outputs and place the loop in
manual operation. Do not enable simulation mode unless your application can tolerate these effects,
and be sure to disable simulation mode when you have finished testing.
Related information
Test or tune the system using sensor simulation
14.15
Trim mA outputs
Trimming an mA output calibrates the transmitter's mA output to the receiving device. If
the current trim values are inaccurate, the transmitter will under-compensate or over-
compensate the output.
Troubleshooting
162 Micro Motion
®
Gas Specific Gravity Meters (SGM)
