Specific gravity and molecular weight meters: Compressibility Method and valid ranges for
process variables (continued)
Table 8-2:
Compressibility
Method
Valid range
Temperature Pressure
Specific
gravity % CO2 % N2 % H2
AGA NX-19 Mod
−40 to
+115.556 °C
0 to 137.9
BarA
0.554 to 0.75 0–15% 0–15% N/A
AGA NX-19 Mod 3
0 to 30 °C 0 to 80 BarA 0.554 to
0.691
0–2.50% 0–7% 0–4%
Relative density meters: Compressibility Method and valid ranges for process variablesTable 8-3:
Compressibility
Method
Valid range
Temperature Pressure
Relative
density % CO2 % N2 % H2
SGERG-88
−30 to
+100 °C
0 to 120 BarA 0.55 to 0.9 0–30%
(1)
0–50%
(1)(1)
N/A
(1) The sum of CO2 and N2 must be less than 50%.
7.5 Configure base density calculations using
ProLink III
ProLink III Device Tools > Configuration > Process Measurement > Base Density
Overview
The base density parameters provide data for the base density calculations. Base density
can be reported as a process variable. For specific gravity meters and relative density
meters, base density is required for line density measurement.
Procedure
1. Choose Device Tools > Configuration > Process Measurement > Base Density.
2. Set Density Unit to the unit to be used for base density, and click Apply.
This unit is also used for line density.
3. Set Base Pressure to the pressure value to which density measurements will be
corrected (the reference pressure).
The default is 1 bar absolute. There is no upper limit. You must be using absolute
pressure.
Configure process measurement using ProLink III
Configuration and Use Manual 61
