Procedure
1. Choose Device Tools > Configuration > Process Measurement > Concentration
Measurement.
2. To use a gas variable, set Gas Purity Variable to Specific Gravity, Molecular Weight, or
Relative Density.
Meter Available option
Specific gravity Specific Gravity or Molecular Weight
Molecular weight Specific Gravity or Molecular Weight
Relative density
Relative Density
3. Set Matrix Being Configured to the matrix you want to configure and click Change
Matrix.
4. Set Concentration Units Label to the label to use for the measurement unit.
This selection does not affect measurement. It only selects a label.
5. If you set Concentration Units to Special, enter a string for the custom label.
6. Enter a name for the matrix.
7. Enter the density of the primary constituent of your process gas, in its pure form.
8. Enter the density of the secondary constituent of your process gas, in its pure form.
9. Click Apply.
Next: Select the active concentration matrix using ProLink III
7.8.3
Select the active concentration matrix using ProLink III
You must select the concentration matrix to be used for measurement. Although the
transmitter can store up to six concentration matrices, only one matrix can be used for
measurement at any one time.
Previous: Configure a concentration measurement matrix using ProLink III
1. Choose Device Tools > Configuration > Process Measurement > Concentration
Measurement.
2. Set Active Matrix to the matrix you want to use and click Change Matrix.
Configure process measurement using ProLink III
Configuration and Use Manual 69
