Emerson Micro Motion SGM Series - B.5 Codes and Abbreviations Used in Display Menus

Display codes for process variables (continued)Table B-2:
Code Definition
MW Molecular Weight
CO2 %CO
2
N2 %H
2
H2 %N
2
CO %CO
Energy measurement
CV Calorific Value
WOBBE Wobbe Index
ENRGY/FLOW Energy Flow
B.5 Codes and abbreviations used in display menus
Display codes for measurement unitsTable B-3:
Code Measurement unit
% Percent
%PLATO °Plato
%SOL-V % solution by volume
%SOL-W % solution by weight
°C °Celsius
°F °Fahrenheit
°K °Kelvin
°R °Rankine
ATM Atmospheres
B BBL Beer barrels
BALL °Balling
BAR Bars
BAUMH °Baumé heavy
BAUML °Baumé light
BBBL/D Beer barrels per day
BBBL/H Beer barrels per hour
BBBL/M Beer barrels per minute
BBBL/S Beer barrels per second
BBL Barrels
Using the transmitter display
Configuration and Use Manual 181
